Interior temperature transmitter with 4-20mA output

Ambient temperature transmitter. Indoor use.

Temperature transmitter is specially designed for use in exacting interiors in building energy management and HVAC systems. It designed for easy installation on ordinary KU68 wiring boxes for household switches and sockets.
Large dual line LCD is possible to switch off.
Computerized design ensures long term stability and fail indication. Transmitter is designed for use in non-aggressive environment.

  • code
    T0118
  • Warranty
    3 years
  • In stock
    3 pcs
  • 780.00 AED

Technical data

Measured value

Temperature

TEMPERATURE SENSOR

Measuring range -10 to +50 °C
Accuracy ±0.5 °C
Resolution 0.1 °C

GENERAL TECHNICAL DATA

Operating temperature -10 to +50 °C
Channels internal temperature sensor
Output 4-20 mA
Available temperature units degrees Celsius, degrees Fahrenheit
Configuration of output user adjustable from PC; measured range + value
Power 9-30 Vdc
Protection class IP20
Dimensions 88 x 106 x 33 mm
Weight approx. 150 g
Warranty 3 years
