WebSensor - remote CO2 concentration thermometer hygrometer with Ethernet interface
CO2 concentration, temperature and relative humidity t-line Web sensor. Remote alarm.
Web Sensor with built-in CO2 concentration, relative humidity and temperature sensors.
A multiple point CO2 and temperature adjustment procedure leads to excellent CO2 measurement accuracy over the entire temperature working range; this is a must for process control and outdoor applications. The dual wavelength NDIR CO2 sensing procedure compensates automatically for ageing effects. The CO2 module is highly resistant to pollution and offers maintenance free operation and outstanding long term stability.
High precision capacitive polymer sensor ensures excellent long term calibration stability and ultimate accuracy. Dual line LCD is an advantage. Measured values are also converted to other humidity interpretation: dew point temperature, absolute humidity, specific humidity, mixing ratio and specific enthalpy.
The CO2 concentration is shown on the display or signaled by a color LED.
Processing and analysis of measured data:
- online in COMET Cloud
- COMET Database software
- integration into 3-party systems
-
codeT6541
-
Warranty3 years
-
In stockon request
- 5 587.00 AED
Technical data
Measured value
TEMPERATURE SENSOR
HUMIDITY SENSOR
DEW POINT
CO2 SENSOR
GENERAL TECHNICAL DATA
Optional accessories and download
ac/dc adapter 230Vac to 12Vdc/1A, EU
ac/dc adapter 230Vac to 12Vdc/1A, UK
ac/dc adapter 230Vac to 12Vdc/1A, US
COMET Cloud Lite for Android & iOS
TL-POE10R - PoE splitter
Software
Comet Database One Click Installer (21.1-IV)
Database Viewer 3.20.0.0 dbapi 21.1
TSensor (3-5-2-0)
Sensor Reader (2-0-8-0)
Conversions - application for recalculation of values
COMET Cloud Lite - Android (Google Play)
COMET Cloud Lite - iOS (App Store)
Others
3D model T6541
Terms and Conditions COMET System s.r.o.
Manuals
Instruction Manual
Quick Start Manual
Declaration of Conformity
How to add WebSensor to COMET Cloud
MIB
Software development kit (SDK)
Catalogs
CATALOG - CO2
CATALOG - WebSensor with Ethernet output
DATASHEET - WebSensor with Ethernet output
