Sixteen Channel Data Logger with Alarms
The complete solution for monitoring of temperature, humidity, pressure, CO2, voltage, current, pulses, events and other signals. Universal configurable inputs and outputs. For desktop use with rubber feet - see Optional accessories. For mounting to 19" rack - one rack unit 1U.
Data loggers are designed for measuring, recording, evaluation and subsequent processing of input electrical signals, which are subject to relatively slow changes (> 1s). In conjunction with the appropriate sensors and transducers are suitable for monitoring physical quantities.
The device includes traceable calibration certificate with declared metrological traceability of etalons is based on requirements of EN ISO / IEC 17025. The calibration sheet is always loaded as modules.
If the defined required configuration of inputs by, calibration certificate proves calibration inputs according to the required configuration - more than one range for each of the 16 inputs.
Processing and analysis of measured data with connected Ethernet module:
- online in COMET Cloud
- COMET Database software
-
codeMS6R
-
Warranty3 years
- On request
Technical data
Measured value
Temperature
Relative humidity
Current
Voltage
Two-state signal
Frequency
Resistance
Event logging
GENERAL TECHNICAL DATA
Operating temperature
0 to +50 °C
Channels
1 to 16 inputs - software configurable
Memory
2MB (up to 480 000 values)
Memory type
internal SRAM, backed-up by Lithium battery
Recording interval
adjustable individually for all input channels from 1 second to 24 hours
Recording interval
noncyclic - data logging stops after filling the memory
cyclic - after filling memory oldest data is overwritten by new
cyclic - after filling memory oldest data is overwritten by new
Real time clock
year, leap year, month, day, hour, minute, second, backed-up by Lithium battery
Resolution of the AD converter (analog channels)
16 bits, conversion duration approximately 60ms/channel
Communication speed
9600, 19200, 57600, 115200 Bd, 230400* Bd (* pro USB, Ethernet)
Communication protocol
www, XML, SNMP, SOAP, ModbusTCP
Alarm protocols
email, SNMP trap, Syslog
Power
24 Vdc
Protection class
IP20
Dimensions (including connectors)
225 x 230 x 44 mm - one rack unit 1U
Dimensions without rack holders
225 x 230 x 44 mm - one rack unit 1U
Weight
approx. 800 g
Warranty
3 years
Parameters of configurable inputs
Optional accessories and download
Temperature probe Pt1000TG8/0, without connector
Temperature range: -80 to 200°C
code
SN104
Price
On request
In stock
118 pcs
Temperature probe Pt1000TG8/0, without connector, cable 2 meters
Temperature range: -80 to 200°C
code
SN105
Price
On request
In stock
268 pcs
Temperature probe Pt1000TG8/0, without connector, cable 5 meters
Temperature range: -80 to 200°C
code
SN108
Price
On request
In stock
159 pcs
Temperature probe Pt1000TG8/0, without connector, cable 10 meters
Temperature range: -80 to 200°C
code
SN113
Price
On request
In stock
69 pcs
Temperature probe 2061-250/0, without connector
Temperature range: -30 to 250°C
code
SN147
Price
On request
In stock
on request
Temperature probe 2061-250/0, without connector, cable 2 meters
Temperature range: -30 to 250°C
code
SN148
Price
On request
In stock
on request
Temperature probe 2061-250/0, without connector, cable 5 meters
Temperature range: -30 to 250°C
code
SN151
Price
On request
In stock
2 pcs
Temperature probe 2061-250/0, without connector, cable 10 meters
Temperature range: -30 to 250°C
code
SN156
Price
On request
In stock
on request
Temperature probe Pt1000TG7/0, without connector
Temperature range: -50 to 200°C
code
SN164
Price
On request
In stock
20 pcs
Temperature probe Pt1000TG7/0, without connector, cable 2 meters
Temperature range: -50 to 200°C
code
SN165
Price
On request
In stock
21 pcs
Temperature probe Pt1000TG7/0, without connector, cable 5 meters
Temperature range: -50 to 200°C
code
SN166
Price
On request
In stock
31 pcs
Temperature probe Pt1000TG7/0, without connector, cable 10 meters
Temperature range: -50 to 200°C
code
SN167
Price
On request
In stock
85 pcs
Temperature probe 2304-220/0, without connector, cable 1 meter
Temperature range: -30 to 220°C
code
SN168
Price
On request
In stock
6 pcs
Temperature probe 2021-150/0, without connector, cable 1 meter
Temperature range: -30 to 150°C
code
SN169
Price
On request
In stock
3 pcs
Temperature probe PTS350A-2/0, without connector, cable 2 meters
Temperature range: -30 to 130°C
code
SN170
Price
On request
In stock
9 pcs
Temperature probe 2034-220/0, without connector, cable 1 meter
Temperature range: -30 to 150°C
code
SN175
Price
On request
In stock
10 pcs
Temperature probe 2061-200/0, without connector, cable 1 meter
Temperature range: -50 to 200°C
code
SN178
Price
On request
In stock
10 pcs
Temperature probe 2061-200/0, without connector, cable 2 meters
Temperature range: -50 to 200°C
code
SN179
Price
On request
In stock
11 pcs
Temperature probe 2061-200/0, without connector, cable 5 meters
Temperature range: -50 to 200°C
code
SN180
Price
On request
In stock
10 pcs
Temperature probe 2061-200/0, without connector, cable 10 meters
Temperature range: -50 to 200°C
code
SN181
Price
On request
In stock
on request
Temperature probe PTS350A-5/0, without connector, cable 5 meters
Temperature range: -30 to 130°C
code
SN182
Price
On request
In stock
11 pcs
Temperature probe PTS350A-10/0, without connector, cable 10 meters
Temperature range: -30 to 130°C
code
SN183
Price
On request
In stock
6 pcs
Temperature probe Pt1000TGL40/0, without connector, cable 1 meter
Temperature range: -30 to 80°C
code
SN185
Price
On request
In stock
16 pcs
Temperature probe Pt1000TGL40/0, without connector, cable 2 meters
Temperature range: -30 to 80°C
code
SN186
Price
On request
In stock
8 pcs
Temperature probe Pt1000TGL40/0, without connector, cable 5 meters
Temperature range: -30 to 80°C
code
SN187
Price
On request
In stock
43 pcs
Temperature probe Pt1000TGL40/0, without connector, cable 10 meters
Temperature range: -30 to 80°C
code
SN188
Price
On request
In stock
23 pcs
Temperature probe Pt1000TR160/0, without connector, cable 1 meter
Temperature range: -30 to 80°C
code
SN199
Price
On request
In stock
28 pcs
Temperature probe Pt1000TR160/0, without connector, cable 2 meters
Temperature range: -30 to 80°C
code
SN200
Price
On request
In stock
18 pcs
Temperature probe Pt1000TR160/0, without connector, cable 5 meters
Temperature range: -30 to 80°C
code
SN201
Price
On request
In stock
76 pcs
Temperature probe Pt1000TR160/0, without connector, cable 10 meters
Temperature range: -30 to 80°C
code
SN202
Price
On request
In stock
153 pcs
Temperature probe Pt1000TR160/0, without connector, cable 15 meters
Temperature range: -30 to 80°C
code
SN203
Price
On request
In stock
117 pcs
Temperature probe Pt1000TR160/0, without connector, cable 20 meters
Temperature range: -30 to 80°C
code
SN204
Price
On request
In stock
58 pcs
PTS380K/0 temperature sensor with a stainless steel connection head and connector
Temperature range: -30 to 100°C
code
SN205
Price
On request
In stock
1 pcs
Stick-in probe 2091-250/0, without connector, cable 1 meter
Temperature range: -50 to 250°C
code
SN210
Price
On request
In stock
4 pcs
Stick-in probe 2091-250/0, without connector, cable 2 meters
Temperature range: -50 to 250°C
code
SN211
Price
On request
In stock
3 pcs
Stick-in probe 2091-250/0, without connector, cable 5 meters
Temperature range: -50 to 250°C
code
SN212
Price
On request
In stock
2 pcs
Stick-in probe 2091-250/0, without connector, cable 10 meters
Temperature range: -50 to 250°C
code
SN213
Price
On request
In stock
on request
Special probe 2071-80/0, without connector
Temperature range: -30 to 80°C
code
SN214
Price
On request
In stock
4 pcs
Temperature probe Pt1000TG68/0, without connector, cable 2 meters
Temperature range: -50 to 200°C
code
SN232
Price
On request
In stock
18 pcs
Temperature probe Pt1000TG68/0, without connector, cable 5 meters
Temperature range: -50 to 200°C
code
SN233
Price
On request
In stock
22 pcs
Temperature probe Pt1000TG68/0, without connector, cable 10 meters
Temperature range: -50 to 200°C
code
SN234
Price
On request
In stock
5 pcs
Temperature probe Pt1000TR125/0, without connector, cable 1 meter
Temperature range: -190 to 150°C
code
SN239
Price
On request
In stock
8 pcs
Temperature probe Pt1000TR125/0, without connector, cable 2 meters
Temperature range: -190 to 150°C
code
SN240
Price
On request
In stock
4 pcs
Temperature probe Pt1000TR125/0, without connector, cable 5 meters
Temperature range: -190 to 150°C
code
SN241
Price
On request
In stock
9 pcs
Cryogenic temperature probe Pt1000TR125/0, without connector, cable 10 meters
Temperature range: -190 to 150°C
code
SN242
Price
On request
In stock
17 pcs
Temperature probe Pt1000TR050S/0, without connector, cable 1 meter
Temperature range: -50 to 400°C
Discontinued
Temperature probe Pt1000TR050S/0, without connector, cable 2 meters
Temperature range: -50 to 400°C
Discontinued
Temperature probe Pt1000TR050S/0, without connector, cable 5 meters
Temperature range: -50 to 400°C
Discontinued
Ultra thin temperature probe Pt1000TG3/0, without connector
Temperature range: -50 to 200°C
code
SN252
Price
On request
In stock
117 pcs
Ultra thin temperature probe Pt1000TG3/0, without connector, cable 2 meters
Temperature range: -50 to 200°C
code
SN254
Price
On request
In stock
93 pcs
Ultra thin temperature probe Pt1000TG3/0, without connector, cable 5 meters
Temperature range: -50 to 200°C
code
SN255
Price
On request
In stock
132 pcs
Ultra thin temperature probe Pt1000TG3/0, without connector, cable 10 meters
Temperature range: -50 to 200°C
code
SN256
Price
On request
In stock
21 pcs
Temperature probe Pt1000TR050S/0, without connector, cable 10 meters
Temperature range: -50 to 400°C
Discontinued
Ambient temperature probe, 201-80/C
Temperature range: -30 to 80°C
code
SN258
Price
On request
In stock
30 pcs
Temperature probe Pt1000TG8Ex/0, without connector, for ATEX zone II
Temperature range: -30 to 180°C
code
SN263
Price
On request
In stock
1 pcs
Temperature probe Pt1000TG8Ex/0, without connector, for ATEX zone II, cable 2 meters
Temperature range: -30 to 180°C
code
SN264
Price
On request
In stock
1 pcs
Temperature probe Pt1000TG8Ex/0, without connector, for ATEX zone II, cable 5 meters
Temperature range: -30 to 180°C
code
SN265
Price
On request
In stock
on request
Temperature probe Pt1000TG8Ex/0, without connector, for ATEX zone II, cable 10 meters
Temperature range: -30 to 180°C
code
SN266
Price
On request
In stock
on request
Temperature probe Pt1000TG8Ex/0, without connector, for ATEX zone II, cable 15 meters
Temperature range: -30 to 180°C
code
SN267
Price
On request
In stock
on request
Temperature probe Pt1000TR050M/0, without connector, cable 1 meter
Temperature range: -50 to 400°C
code
SN270
Price
On request
In stock
5 pcs
Temperature probe Pt1000TR050M/0, without connector, cable 2 meters
Temperature range: -50 to 400°C
code
SN271
Price
On request
In stock
9 pcs
Temperature probe Pt1000TR050M/0, without connector, cable 5 meters
Temperature range: -50 to 400°C
code
SN272
Price
On request
In stock
11 pcs
Temperature probe Pt1000TR050M/0, without connector, cable 10 meters
Temperature range: -50 to 400°C
code
SN273
Price
On request
In stock
on request
Thermocouple "K" surface probe, CP500
Temperature range: -65 to 500°C
code
CP500
Price
On request
In stock
4 pcs
Thermocouple "K" stick-in probe, CZ550
Temperature range: -65 to 550°C
code
CZ550
Price
On request
In stock
4 pcs
Thermocouple "K" stick-in probe, CZ900
Temperature range: -65 to 1000°C
code
CZ900
Price
On request
In stock
6 pcs
Thermocouple "K" wire probe, GD1250, without connector
Temperature range: -65 to 980°C
code
GD1250-1/0
Price
On request
In stock
on request
Thermocouple "K" wire probe, GD1250, without connector, 2 meters
Temperature range: -65 to 980°C
code
GD1250-2/0
Price
On request
In stock
on request
Thermocouple "K" wire probe, GD1250, without connector, 3 meters
Temperature range: -65 to 980°C
code
GD1250-3/0
Price
On request
In stock
on request
Thermocouple "K" wire probe, GD1250, without connector, 4 meters
Temperature range: -65 to 980°C
code
GD1250-4/0
Price
On request
In stock
on request
Thermocouple "K" wire probe, GD260, without connector
Temperature range: -65 to 260°C
code
GD260-1/0
Price
On request
In stock
on request
Thermocouple "K" wire probe, GD260, without connector, 2 meters
Temperature range: -65 to 260°C
code
GD260-2/0
Price
On request
In stock
on request
Thermocouple "K" wire probe, GD260, without connector, 3 meters
Temperature range: -65 to 260°C
code
GD260-3/0
Price
On request
In stock
on request
Thermocouple "K" wire probe, GD260, without connector, 4 meters
Temperature range: -65 to 260°C
code
GD260-4/0
Price
On request
In stock
on request
Thermocouple "K" wire probe, GD700, without connector
Temperature range: -65 to 700°C
code
GD700-1/0
Price
On request
In stock
on request
Thermocouple "K" wire probe, GD700, without connector, 2 meters
Temperature range: -65 to 700°C
code
GD700-2/0
Price
On request
In stock
on request
Thermocouple "K" wire probe, GD700, without connector, 3 meters
Temperature range: -65 to 700°C
code
GD700-3/0
Price
On request
In stock
on request
Thermocouple "K" wire probe, GD700, without connector, 4 meters
Temperature range: -65 to 700°C
code
GD700-4/0
Price
On request
In stock
on request
Thermocouple "K" insertion probe, GT1150
Temperature range: -50 to 1150°C
code
GT1150
Price
On request
In stock
8 pcs
Extension cable thermocouple "K"
code
SNP03
Price
On request
In stock
on request
Extension cable thermocouple "K" female connector
code
SNP03/0
Price
On request
In stock
on request
Extension cable thermocouple "K", 2 meters
code
SNP06
Price
On request
In stock
on request
Extension cable thermocouple "K" female connector, 2 meters
code
SNP06/0
Price
On request
In stock
on request
Extension cable thermocouple "K", 3 meters
code
SNP07
Price
On request
In stock
on request
Extension cable thermocouple "K" female connector, 3 meters
code
SNP07/0
Price
On request
In stock
on request
Extension cable thermocouple "K", 4 meters
code
SNP08
Price
On request
In stock
on request
Extension cable thermocouple "K" female connector, 4 meters
code
SNP08/0
Price
On request
In stock
on request
Extension cable thermocouple "K", 5 meters
code
SNP09
Price
On request
In stock
on request
Extension cable thermocouple "K" female connector, 5 meters
code
SNP09/0
Price
On request
In stock
on request
Extension cable thermocouple "K", 6 meters
code
SNP10
Price
On request
In stock
on request
Extension cable thermocouple "K" female connector, 6 meters
code
SNP10/0
Price
On request
In stock
on request
Extension cable thermocouple "K", 7 meters
code
SNP11
Price
On request
In stock
on request
Extension cable thermocouple "K" female connector, 7 meters
code
SNP11/0
Price
On request
In stock
on request
Extension cable thermocouple "K", 8 meters
code
SNP12
Price
On request
In stock
on request
Extension cable thermocouple "K" female connector, 8 meters
code
SNP12/0
Price
On request
In stock
on request
Extension cable thermocouple "K", 9 meters
code
SNP13
Price
On request
In stock
on request
Extension cable thermocouple "K" female connector, 9 meters
code
SNP13/0
Price
On request
In stock
on request
Extension cable thermocouple "K", 10 meters
code
SNP14
Price
On request
In stock
on request
Extension cable thermocouple "K" female connector, 10 meters
code
SNP14/0
Price
On request
In stock
on request
Extension cable thermocouple "K", 11 meters
code
SNP15
Price
On request
In stock
on request
Extension cable thermocouple "K" female connector, 11 meters
code
SNP15/0
Price
On request
In stock
on request
Extension cable thermocouple "K", 12 meters
code
SNP16
Price
On request
In stock
on request
Extension cable thermocouple "K" female connector, 12 meters
code
SNP16/0
Price
On request
In stock
on request
Extension cable thermocouple "K", 13 meters
code
SNP17
Price
On request
In stock
on request
Extension cable thermocouple "K" female connector, 13 meters
code
SNP17/0
Price
On request
In stock
on request
Extension cable thermocouple "K", 14 meters
code
SNP18
Price
On request
In stock
on request
Extension cable thermocouple "K" female connector, 14 meters
code
SNP18/0
Price
On request
In stock
on request
Extension cable thermocouple "K", 15 meters
code
SNP19
Price
On request
In stock
on request
Extension cable thermocouple "K" female connector, 15 meters
code
SNP19/0
Price
On request
In stock
on request
Ac/dc adapter 21V/1A/25W unstabilized
code
A1759
Price
On request
In stock
on request
AC/DC adapter 230Vac to 24Vdc/1A, switch-mode, EU
code
A1940eu
Price
On request
In stock
42 pcs
AC/DC adapter 230Vac to 24Vdc/1A, switch-mode, UK
code
A1940uk
Price
On request
In stock
on request
AC/DC adapter 230Vac to 24Vdc/1A, switch-mode, US
code
A1940us
Price
On request
In stock
on request
Power supply 24Vdc for DIN 35mm rail
code
A5948
Price
On request
In stock
on request
Uninterruptible power supply MIN-DC-UPS/24VDC/2
code
A6963
Price
On request
In stock
on request
Uninterruptible power supply unit AWZ 224
code
A6966
Price
On request
In stock
8 pcs
Rechargeable battery module MINI-BAT/24DC/1,3AH
code
A7963
Price
On request
In stock
on request
Rechargeable hermetic battery 12V/7,2Ah
code
A7966
Price
On request
In stock
4 pcs
Accredited calibration of 1-8 inputs of the MS Monitoring System
code
SLU004
Price
On request
In stock
on request
Accredited calibration of 1-16 inputs of the MS Monitoring System
code
SLU005
Price
On request
In stock
on request
KIT-GSM with modem GSM
code
KIT-GSM-M
Price
On request
In stock
on request
Antenna for GSM modem
code
MP009/1
Price
On request
In stock
138 pcs
Communication cable for GSM modem
code
MP009/2
Price
On request
In stock
6 pcs
Communication cable for ext. terminal or output relays module 60cm
code
MP017
Price
On request
In stock
13 pcs
Communication cable for ext. terminal or output relays module 10m
code
MP017-10
Price
On request
In stock
on request
Communication cable for ext. terminal or output relays module 5m
code
MP017-5
Price
On request
In stock
on request
Converter RS232/485/422 to 10/100Base-TX with ac/dc adapter for MS
code
MP023
Price
On request
In stock
on request
Four rubber feet for MS6R
code
MP041
Price
On request
In stock
on request
Ethernet communication port (internal) for MS6R, MS6D
code
MP042
Price
On request
In stock
12 pcs
2G/4G RS232 modem - without accessories
code
MP054
Price
On request
In stock
5 pcs
Plug&Play LTE router for data communication between MS and COMET Cloud
code
MP056
Price
On request
In stock
on request
Galvanically isolated input for MS data loggers for serial RS485 signal
code
RS485IN
Price
On request
In stock
3 pcs
Holders for output relays module mounting to DIN 35mm rail
code
MP019
Price
On request
In stock
21 pcs
DIN rail 35mm/226mm lenght with screws
code
MP035
Price
On request
In stock
on request
DIN rail 35mm/226mm lenght with screws
code
MP035
Price
On request
In stock
on request
COMET Database
code
CDB
Price
On request
In stock
yes
COMET Cloud
code
cloud
Price
On request
In stock
yes
COMET Cloud Lite for Android & iOS
code
cloud_app
Price
On request
In stock
yes
Database Viewer for Comet Database
code
DBV
Price
On request
In stock
yes
Software for COMET Monitoring Systems
code
SWR003
Price
On request
In stock
yes
Communication cable for ext. terminal or output relays module 60cm
code
MP017
Price
On request
In stock
13 pcs
Communication cable for ext. terminal or output relays module 10m
code
MP017-10
Price
On request
In stock
on request
Communication cable for ext. terminal or output relays module 5m
code
MP017-5
Price
On request
In stock
on request
Output relays module
code
MP018
Price
On request
In stock
on request
Holders for output relays module mounting to DIN 35mm rail
code
MP019
Price
On request
In stock
21 pcs
DIN rail 35 mm for output relays module with screws
code
MP020
Price
On request
In stock
9 pcs
Terminal with display for MS55, MS6
code
MP016
Price
On request
In stock
on request
Communication cable for ext. terminal or output relays module 60cm
code
MP017
Price
On request
In stock
13 pcs
Communication cable for ext. terminal or output relays module 10m
code
MP017-10
Price
On request
In stock
on request
Communication cable for ext. terminal or output relays module 5m
code
MP017-5
Price
On request
In stock
on request
External terminal for MS6x and MS55D dataloggers with housing and cable
code
MP032
Price
On request
In stock
on request
Watertight case with wall holders for MS logger, no cutout in the lid
code
MP033
Price
On request
In stock
on request
MS55D datalogger in IP54 protection case with connected terminal at the lid
code
MP049
Price
On request
In stock
on request
Motion detector JS20
code
JS20
Price
On request
In stock
3 pcs
The LD-12 flood detector
code
LD12
Price
On request
In stock
29 pcs
Magnetic door contact SA-200-A
code
SA200A
Price
On request
In stock
86 pcs
Magnetic door contact with cable length 10m
code
SA200A-10
Price
On request
In stock
on request
Magnetic door contact with cable length 15m
code
SA200A-15
Price
On request
In stock
on request
Magnetic door contact with cable length 2m
code
SA200A-2
Price
On request
In stock
on request
Magnetic door contact with cable length 20m
code
SA200A-20
Price
On request
In stock
on request
Magnetic door contact with cable length 30m
code
SA200A-30
Price
On request
In stock
on request
Magnetic door contact with cable length 5m
code
SA200A-5
Price
On request
In stock
on request
The optical smoke detector SD-283ST
code
SD280
Price
On request
In stock
11 pcs
Power detector SP008
code
SP008
Price
On request
In stock
2 pcs
External audio unit for MSxx and Multilogger
code
MP026
Price
On request
In stock
2 pcs
Screwdriver for WAGO terminals 3.5mm
code
MP031
Price
On request
In stock
on request
Software
SWR003 (MSPlus 4.0.46.0 dbapi 21.1)
Comet Database One Click Installer (21.1-V)
Database Viewer 3.20.0.0 dbapi 21.1
Conversions - application for recalculation of values
COMET Cloud Lite - Android (Google Play)
COMET Cloud Lite - iOS (App Store)
Others
Terms and Conditions COMET System s.r.o.
Manuals
Instruction Manual - basic
Instruction Manual - appendix
Declaration of Conformity
MIB
Configurable inputs for MS6xx
Monitoring System setup wizard step by step - powerpoint
Catalogs
CATALOG - Monitoring Systems
Catalogue Sheets - COMET Analytical Software
Catalogue Sheets - COMET MS Monitoring Systems
Related products
COMET Database
code
CDB
Price
On request
In stock
yes
Software for COMET Monitoring Systems
code
SWR003
Price
On request
In stock
yes
Ethernet Multilogger - universal datalogger with 4 inputs
code
M1300
Price
On request
In stock
3 pcs
Sixteen Channel Data Logger with Alarms
code
MS6D
Price
On request
In stock
on request
Sixteen Channel Data Logger for 19" Rack with Alarms
code
MS6-Rack
Price
On request
In stock
on request
Sixteen Channel Data Logger with Alarms
code
MS55D
Price
On request
In stock
4 pcs
Database Viewer for Comet Database
code
DBV
Price
On request
In stock
yes
